Model ID

RS-VIVC-BSE-D1

Configure and Buy
{{spec.DisplayName}} - {{spec.Value}}
Find a Dealer
Where to buy

Ships after .

Currently out of stock until .

Description
Find a Dealer

There’s a reason everyone loves coil—the feel is unmistakable—supple off the top, supportive through the mid-stroke, and backed by a large bottom-out bumper—giving you unwavering consistency and predictability. Engineered to work as a system with your RockShox fork damper, the R damper’s new main piston compression tunes provide mid-stroke support. Distilling decades of coil dominance into a shock built for today’s enduro, E-MTB, and downhill bikes, Vivid Coil carries the unmistakable heritage of coil into a new era of performance.

Read More
Read Less
Features
  • NEW R damper providing an easy-to-use Rebound adjuster
  • NEW Base valve with 40% reduction in IFP forces, making it the most supple shock on the market while maintaining perfect traction
  • NEW Main piston compression tunes matched in performance to the Charger 3.2 damper, focused on providing mid-stroke support
  • 20 clicks of Rebound adjustment providing uniform rebound curves paired with a broad adjustment range provide a consistent ride feel for a wide spectrum of rider weights
  • 8x30 Bearing Adapter available for all standard eyelets, configured as hardware (upcharge applies)
See more features
See less features

Vivid Coil

Specifications

Eye to eye / Stroke 185x47.5(TR), 185x50(TR), 185x52.5(TR), 185x55(TR), 205x57.5(TR), 205x60(TR), 205x62.5(TR), 205x65(TR), 210x47.5, 210x50, 210x52.5, 210x55, 225x67.5(TR), 225x70(TR), 225x72.5(TR), 225x75(TR), 230x57.5, 230x60, 230x62.5, 230x65, 250x67.5, 250x70, 250x72.5, 250x75
Damper Type R
Rebound tune R25, R55
Compression tune C22, C26, C30, C34, C37, C40, C43
Lockout force N/A-V5
Shaft Eyelet No Bushing, No Bushing - 270 Deg Rotation, No Bushing - 90 Deg Rotation, Standard, Standard - 180 Deg Rotation, Standard - 75 Deg Rotation, Standard - 90 Deg Rotation
Body Eyelet No Bushing, Standard, Trunnion
E-Bike Approved E-bike Approved
Bottom Out n/a
High Speed Tune H1, H2
